Unicla UP-170 - Magnetic Clutch; Rear Cap

2.
Magnetic clutch
Rear cap for UP90, 120, 150, 170
Rear caps and hose ports available for Unicla A series compressors
Clutches available for Unicla A series compressors - pulley diameter (mm) and voltage
Type 119 120 125 130 132 133 135 137 140 141 145 150 152 12V 24V
A Groove • • • • • •
AA Groove • • • • • •
B Groove • • • •
BB Groove • • • • •
4 Groove • • • • • •
5 Groove • • • • • •
6 Groove • • • • • • •
8 Groove • • •
10 Groove • • •
1. U = Vertical Hose Ports
2. D = Horizontal Hose Ports
3. FN = Flange Hose Ports
4. Relief valve is also available on the cap
5. Use the type no’s shown in each box when selecting compressor model
FN8FN1DO1
DO2
UO1
UO2
UO3
FN2 FN6
Cap type U DD FN
Hose port O ring O ring Flange
No
charging
ports
With
charging
ports
With
charging
ports
