UNICORECOMM UM982 - 2 Hardware; 2.1 Dimensions

UM982 User Manual
6 Hardware UC-00-M31 EN P1.0.0
 Reset (RESET_N)
Active LOW, and the active time should be no less than 5 ms.
2 Hardware
2.1 Dimensions
Table 2-1 Dimensions
Parameter
Min. (mm)
Typ. (mm)
Max. (mm)
A
20.80
21.00
21.50
B
15.80
16.00
16.50
C
2.40
2.60
2.80
D
2.78
2.88
2.98
E
0.95
1.05
1.15
F
1.55
1.65
1.75
G
1.17
1.27
1.37
H
0.70
0.80
0.90
K
1.40
1.50
1.60
M
4.10
4.20
4.30
N
3.70
3.80
3.90
P
2.00
2.10
2.20
R
0.90
1.00
1.10
X
0.72
0.82
0.92
