General| Wireless Standards | 802.11 a/b/g/n/ac |
|---|---|
| Frequency Bands | 2.4 GHz, 5 GHz |
| MIMO | 2x2 |
| Wireless Security | WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) |
| Maximum Power Consumption | 6.5W |
| Max. TX Power | 20 dBm |
| Operating Temperature | -10 to 70° C (14 to 158° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
| Maximum Throughput | 300 Mbps (2.4 GHz), 867 Mbps (5 GHz) |
| Ports | 1x 10/100/1000 Ethernet Port |
| Power Method | PoE (802.3af), 24V passive PoE |
| Dimensions | 160 x 31.45 mm (6.3 x 1.24") |
| Weight | 170 g |
| Power Supply | 24V, 0.5A Gigabit PoE Adapter |
| Data Rates | 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps; 802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40); 802.11ac: 6.5 Mbps to 867 Mbps (MCS0 - MCS9, NSS1/2, VHT 20/40/80) |
| Antenna | Internal |
| Mounting | Wall/Ceiling |
