Unigas C85A - Technical Specifications

PART I: SPECIFICATIONS
7
Technical Specifications
Gas categories and countries of application
BURNER TYPE C85A M-.. C120A M-.. C85A L-.. C120A L-..
Output min. - max. kW
230 - 850 300 - 1200 230 - 850 300 - 1200
Fuel
Natural gas
L.P.G.
Category see next paragraph
I
3B/P
Gas flow rate
min.-max. Stm
3
/h
24 - 90 32 - 127 8.6 - 32 11,2 - 45
Gas pressure min.-max. mbar
(see Note 2)
Electric supply
230V 3~ / 400V 3N ~ 50Hz
Total power consumption kW
1,6 2 1,6 2
Fan motor kW
1,1 1,5 1,1 1,5
Protection
IP40
Operation
Progressive - Fully modulating
Valves size / Gas connection - 32
1"
1/4
/ Rp 1
1/4
-
1"
1/4
/ Rp 1
1/4
-
Valves size / Gas connection - 40
1"
1/2
/ Rp 1
1/2
1"
1/2
/ Rp 1
1/2
1"
1/2
/ Rp 1
1/2
1"
1/2
/ Rp 1
1/2
Valves size / Gas connection - 50
2"
/ Rp 2 2" / Rp 2 2" / Rp 2 2" / Rp 2
Valves size / Gas connection - 65
2"
1/2
/ DN65 2"
1/2
/ DN65 2"
1/2
/ DN65 2"
1/2
/ DN65
Valves size / Gas connection - 80
-
3"
/ DN80
-
3" / DN80
Operating temperature °C
-10 ÷ +50
Storage Temperature °C
-20 ÷ +60
Working service* Continuous
Note1:
All gas flow rates are referred to Stm
3
/ h (1.013 mbar absolute pressure, 15 °C temperature) and are valid for G20 gas
(net calorific value H
i
= 34,02 MJ / Stm
3
); for L.P.G. (net calorific value H
i
= 93,5 MJ / Stm
3
)
Note2: Maximum gas pressure = 360 mbar (with Dungs MBDLE)
= 500 mbar (with Siemens VGD or Dungs MultiBloc MBE)
Minimum gas pressure = see gas curves.
Note3: Burners are suitable only for indoor operation with a maximum relative humidity of 80 %
GAS CATEGORY
COUNTRY
I
2H
AT, ES, GR, SE, FI, IE, HU, IS, NO, CZ, DK, GB, IT, PT, CY, EE, LV, SI, MT, SK, BG, LT, RO, TR, CH
I
2E
LU, PL
I
2E( R ) B
BE
I
2EK
NL
I
2ELL
DE
I
2Er
FR
