Page 6 For technical questions, please call 1-888-866-5797. Item 59549
Mounting
WARNING! TO PREVENT SERIOUS INJURY:
Verify that installation surface has no hidden
utility lines before drilling or driving screws.
1. Place Safe in desired location. Use
a pencil to mark the mounting holes
on surface. Set Safe aside.
2. To mount to concrete:
a. Drill 1.6″ (40 mm) deep mounting holes
using a 9 mm drill bit (not included).
b. Insert anchor (included) into the
mounting holes. See Figure A.
Anchor
Mounting
Surface
Figure A: Installing Anchors
c. Move Safe back in place. Align safety device
over mounting holes. Secure device with
tapping screws (included). See Figure B.
Mounting
Hole
Tapping
Screw
Anchor
Figure B: Mounting Safe
to Concrete Surface
3. To mount to wooden surface:
a. Place Safe in desired location.
b. Secure Safe by driving tapping screws
through the mounting holes in the
bottom of the safe. See Figure C.
Mounting
Hole
Tapping
Screw
Figure C: Mounting Safe
to Wooden Surface
To Next Page
