Page 10
POWERING TECHNOLOGY
Manual No. aspiro2u-3
aspiro2u_m23-man-rev3-0516.indd
RECTIFIER MODEL XPGe12.48 XR08.48 XR04.48
E󰀩ciency 95% typical @ I
out
nom 90% typical @ I
out
nom 88% typical @ I
out
nom
Input Current (max) <7.3A <10.5A <5.3A
Output Current (max)
53.5V oat
22.4A 15.0A 7.5A
Output Power 1200W @ >180VAC
750W @ 90-180VAC
800W 400W
Operating Temperature
(without derating)
55°C 65°C 65°C
Input Voltage
(Nominal 100-240VAC)
90-300VAC 85-300VAC
Output Voltage 46-57VDC
Load sharing < 5% of nominal current
Dimensions (WxHxD) 40.6 (1.6”) x 101.62(4”) x 228.5(9”) mm
Weight 1.1 kg
Cooling Fan-cooled, speed and alarm controlled, air ow direction rear to front
Protection Short circuit proof, automatic current limiting, selective shutdown of modules
at excessive output voltage.
Alarms High output voltage/ shutdown, Low voltage/ module failure
LED Indication
Green: Power ON
Yellow: Current limit/ thermal protection
Fan failure / Over temperature
Pre-warning / thermal protection
Communication Failure (ashing)
Red: Module failure / high output voltage shutdown
Audible noise <55dBA according to ISO7779
MECHANICAL
Dimensions (WxHxD) 19” (483mm) x 3.5” (88mm) x 11.7” (297mm)
Weight of the system
(fully equipped)
32lbs (14.5kg)
Mounting Options 19”/ ETSI / Mid-mount
Cable Entry Rear Access (top cover has to be removed to make connections)
STANDARD COMPLIANCE / ENVIRONMENTAL
EMC and Immunity EN55022:2006 +A1:2007, EN55024:1998 +A1:2001 +A2:2003,
EN61000-3-2:2006+A1:2009 +A2:20009, EN61000-3-3:2008
ETSI EN300386 V1.4.1
Safety EN60950-1: 2006 + A11:2009
Environment
Storage : ETS300 019-2-1, Transport: ETS300 019-2-2, Operation
ETS300 019-2-3, Damp Heat: IEC60068-2-78
Operating Temperature -40°C to +65°C (derated above 55°C)
Storage Temperature -40°C to +85°C
