UNIQUE 24& 30
12
ALIGNMENTS AND ADJUSTMENTS
Installation
It is the responsibility of the installer to make certain that the range is properly
adjusted at the time of installation. Situations caused by improper adjustments or
improper installation are not covered under the warranty. Any expenses incurred due
to such situations will not be paid by the manufacturer of the appliance.
Gas Range Conversion and Adjustment Guide
The range will either be set for use with Liquefied Petroleum (LP) or Natural Gas.
The factory setting is indicated on the serial plate. When set for Natural Gas
operation, the pressure regulator will regulate the pressure to 4 inches water column.
When set for LP Gas operation, the pressure regulator will regulate the gas to 10
inches water column pressure.
On sealed burner models the main top must be removed to adjust
regulator, thermostat and to install the proper burner orifices
To Next Page
