24” PARTS DIAGRAM AND LIST
Item# Description Part#
1 Backsplashpanel UGP-DWSJ13253
2 Backsplashpanelcover UGP-'DCY14274-1
3 Cookingpanel UGP-'DWSJ13254-4
4 Cookingpanelstopplate UGP-DCY14226
5 Controlpanel UGP-WSJ13340-SY
6 Knobbezel UGP-DCY07049
7 Linerfrontpanel UGP-DWSJ13256
8 Burnerfixedboard UGP-CY14531
9 Linerbackpanel UGP-WSJ13341
10 Linerleftpanel UGP-WSJ13349
11 Linerrightpanel UGP-WSJ13350
12 Linertoppanel UGP-WSJ13342
13 Feetfastenbeam(left) UGP-DCY14237
14 Feetfastenbeam(right) UGP-DCY14238
15 ChimineyA UGP-CY14536
16 ChimineyB UGP-CY14537
17 Linerfastenbeam UGP-CY14538
18 Linerheat-insulatedpanel UGP-CY14539
19 Feetfastenbeam(left) UGP-DWSJ13245
20 Feetfastenbeam(right) UGP-DWSJ13246
21 Ovenflamespreader UGP-DCY14248
22 Thermostatclip UGP-DCY14249
23 Backpanelfixedsupport UGP-'DCY14250
24 Ovenfloor UGP-WSJ13343
25 Backpanel UGP-CY14549
26 Ovendoor UGP-DWSJ13260
27 Ovendoorfastenplate UGP-DCY14295
28 Ovendoorglasssupport UGP-DCY14296
29 Doorheat-insulatedfiberleftpresspanel UGP-DCY14297
30 Doorheat-insulatedfiberrightpresspanel UGP-DCY14298
31 Doorheat-insulatedfiberupperpresspanel UGP-DCY14299
32
Doorheat-insulatedfiberbottompresspanel
UGP-DCY14300
33 coveronthetopofovendoor UGP-DWSJ13261
34 Ovendoorinnerpanel UGP-DWSJ13262
35 Drawerdoor UGP-WSJ13344
36 Drawerinnerpanel UGP-WSJ13345
37 Antitipbracket UGP-DCY14269
38 Ovenrackfixedpart UGP-DCY14270
39 Regulatorfixedpart UGP-DCY14271
40 Castirongratewithdimplets UGP-DWWJ01019-1
41 130burnerassembly UGP-DWWJ01293
42 100burnerassembly UGP-DWWJ01294
43 55burnerassembly UGP-DWWJ01295
44 Nozzle UGP-DPJ24003-DPJ24120
45 IgnitionNeedleforbiggestburner UGP-DXQJ9901
46 Ignitionneedleclip UGP-DWJ9901
47 Knob UGP-DWWS07001
48 Gasvalve UGP-DPJ99170
49 Thermostatvalve UGP-DWWJ01114-6
