No. Item Code
1 Cabinet N/A
2 Heat sink UGP-DL27501852
3 Drip tray UGP-DL22501423
4 Drainage hose UGP-DL00010078
5 Drip pan UGP-DL10001155
6 Hinge cover UGP-DL22501399
7 Screw UGP-DL00003005
8 Screw cap UGP-DL10001193
9 Top hinge UGP-DL22001079
10 Top hinge cover UGP-DL22501398
11 Freezer door - White UGP-DL90000008
11 Freezer door – Black UGP-DL90000009
11 Freezer door - Stainless UGP-DL90000010
12 Fridge door – White UGP-DL90000005
12 Fridge door – Black UGP-DL90000006
12 Fridge Door - Stainless UGP-DL90000007
13 Washer UGP-DL03001603
14 Screw UGP-DL27501364
15 Middle hinge UGP-DL27501359
16 Washer UGP-DL03001602
17 Bottle rack UGP-DL22502213
18 Freezer balcony UGP-DL18502271
19 Fridge balcony UGP-DL22502240
20 Egg tray UGP-DL10001104
21 Ice tray UGP-DL03001003
22 Bottle holder UGP-DL18301133
23 Crisper UGP-DL27501436
23-1 Top wearing plate UGP-DL27501311
24 Bottom hinge UGP-DL27501239
25 Bottom hinge pin UGP-DL02201204
26 Spring washer UGP-DL00003018
27 Screw UGP-DL00003005
28 Control panel UGP-DL27501860
29 Control label UGP-DL27501862
30 Lamp UGP-DL00013598
31 Foot UGP-DL00010053
32 Screw UGP-DL27501495
33 Castor UGP-DL00003068
34 Top shelf UGP-DL27501433
35 Middle shelf UGP-DL27501434
36 Bottom shelf UGP-DL27501435
36-1 Ventilation hood UGP-DL27501310
36-2 Bottom wearing plate UGP-DL27501312
37 Cooling unit UGP-DL22503082
38 Heater UGP-DL27501293
39 Glass wool UGP-DL00006030
40 Insulation cover UGP-DL22501136
40-1 Cover cap UGP-DL22501422
41 Bae UGP-DL27501007
42 Bae holder UGP-DL22502227
43 Checkpoint assembly UGP-DL27501365
43-1 Screw UGP-DL10001474
43-2 Test valve body UGP-DL10001498
43-3 Connector UGP-DL10001501
43-4 Washer UGP-DL00009306
43-5 Screw UGP-DL22501206
44 Injector UGP-DL10001713
No. Item Code
45 Burner assembly UGP-DL6810V3CONKIT
45-1 Burner bracket UGP-DL22502507
45-2 Burner tube support UGP-DL10001476
46 Burner tube UGP-DL10001142
47 Burner cover assembly UGP-DL22502506
47-1 Burner cover UGP-DL22502508
48 Cover window UGP-DL10001186
49 Seal ring UGP-DL10001136
50 Nut UGP-DL10001630
51 Outlet Gas Pipe UGP-DL27501360
52 Inlet Gas Pipe UGP-DL27501382
53 Gas connector UGP-DL10001586
54 Nut UGP-DL00003075
55 Connector bracket UGP-DL10001096
56 Electrode UGP-DL27501257
57 Gas inlet cap UGP-DL00010139
58 Flame indicator UGP-DL10001527
59 Bracket UGP-DL27501355
60 Balcony spacer UGP-DL08502163
61 Connector UGP-DL10001114
62 Thermostat UGP-DL18301115
63 Nut UGP-DL18301029
64 Connector UGP-DL10001405
65 Safety valve UGP-DL18301005
66 Connector UGP-DL10001818
67 Thermocouple UGP-DL10001523
68 Thermostat bracket UGP-DL27501354
69 Power cord holder UGP-DL28801267
70 Rotary switch UGP-DL10001213
71 Bracket UGP-DL27501247
73 Knob UGP-DL27501362
74 Thermostat Wire UGP-DL27501292
75 Thermocouple Wire UGP-DL10001350
76 Front bottom UGP-DL27501328
77 Rear bottom UGP-DL27501329
78 Connector UGP-DL10001406
79 Spring UGP-DL10001145
80 Button UGP-DL18301034
81 Power cord UGP-DL10001252
82 Grounding wire UGP-DL10001056
83 Lamp box UGP-DL04001634
84 Lamp board UGP-DL27501160
85 Lamp cover UGP-DL04001633
86 Lamp box bottom UGP-DL04001632
87 Battery UGP-DL00013848
88 Battery holder UGP-DL27501190
89 Battery cover UGP-DL27501342
90 Lamp switch UGP-DL00013660
91 Battery igniter UGP-DL18301371
92 Pulse Ignition Wire UGP-DL22501187
93 Push button switch UGP-DL18301372
94 Battery UGP-DL00013847
95 Freezer shelf UGP-DL27501249
96 Screw cover UGP-DL27501363
97 Heat Shield UGP-DL22501209
98 Big brush UGP-DL22001096
99 Small brush UGP-DL27501318
23
UGP-10C PARTS DIAGRAM & LIST
