Unison Research Unico Nuovo User Manual

Unison Research

Unico Nuovo
19
7. TECHNICAL SPECIFICATIONS
Power output: 85W RMS on 8 both channels driven
Frequency response: -0.1dB @ 10Hz / -0.5dB @ 100kHz
Input impedance: 47k // 47pF
Sensitivity: 260mV RMS
Input stage: Pure Class A.
Parallel ECC83/12AX7 (2x)
Output stage: Dynamic Class A
POWER MOSFET in complementary pair
Inputs: 5 line RCA (1 phono optional)
Line outputs: 1 tape, 1 sub (volume controlled)
Output connectors: 4 + 4 bi-wiring
Feedback factor: 10dB
THD: < 0.15% @ 1kHz, 10W
Power consumption: 380W max
Dimensions: 17.1in x 3.5in x 17in
Weight: 31lb
PHONO STAGE (optional)
Input impedance: 47k // 220pF MM
100 // 440pF MC
Gain: 40dB MM, 50dB MC
Gain setting: +0dB / +10dB
Max input voltage: 120mV @ 1kHz
RIAA: active at low frequency,
passive at high frequency
THD: 0.09% @ 5mV, 1kHz, MM

Unison Research Unico Nuovo Specifications

Audio Specifications

power output	85W RMS on 8Ω both channels driven
frequency response	-0.1dB @ 10Hz / -0.5dB @ 100kHz
input impedance	47kΩ // 47pF
sensitivity	260mV RMS
feedback factor	10dB
THD	< 0.15% @ 1kHz, 10W

Power

power consumption	380W max

Phono Stage Specifications

phono stage input impedance	47kΩ // 220pF MM
phono stage gain	40dB MM, 50dB MC
max input voltage	120mV @ 1kHz
RIAA	active at low frequency, passive at high frequency
phono stage THD	0.09% @ 5mV, 1kHz, MM

Weight and Dimensions

dimensions	17.1in x 3.5in x 17in
weight	31lb
