Unison Research Unico Primo User Manual

20
DECLARATION OF CONFORMITY
Manufacturer
A.R.I.A. Advanced Research In Audio srl
Via E. Barone, 4
31030 Dosson di Casier (TV)
ITALY
Statement of Conformity
Based on test results using appropriate standards, the product is in conformity with
Electromagnetic Compatibility Directive 89/336/EEC
92/31/EEC
93/68/EEC
Low Voltage Directive 73/23/EEC
93/68/EEC
Sample test
Standard used:
EN 55013-1 : 1993 (and subsequent modifications)
Limits and methods of measurement of radio disturbance
characteristics of broadcast receivers and associated
equipment
EN 61000-3-2 : 1995 (and subsequent modifications)
Electromagnetic compatibility. Part3: Limits – Section 2:
Limits for harmonic current emissions (equipment input
current ≤ 16A per phase)
EN 61000-3-3 : 1995 (and subsequent modifications)
Electromagnetic compatibility. Part3: Limits – Section 2:
Limitation of voltage fluctations and flicker in low-voltage
supply systems for equipment with rated current ≤ 16A
EN 60335; EN 61305-1; EN 61305-3; CEI 84-2; CEI 84-3; CEI 84-8.
The tests have been performed in a typical configuration.
This Conformity is indicated by the symbol , i.e. « Conformité européenne ».

Unison Research Unico Primo Specifications

Power Output

power output	80W RMS on 8Ω both channels driven
power consumption	380W max

Frequency and Impedance

frequency response	-0.1dB @ 10Hz / -0.5dB @ 100kHz
input impedance	47kΩ
feedback factor	10dB

Phono Stage

phono input impedance MM	47kΩ // 220pF
phono input impedance MC	100Ω // 440pF
phono gain MM	40dB
phono gain MC	50dB
phono gain setting	+0dB / +10dB
phono max input voltage	120mV @ 1kHz
phono THD	0.09% @ 5mV, 1kHz, MM

Dimensions and Weight

dimensions	17.1in x 3.5in x 17in
weight	31lb
