Unitech UT-101 F User Manual

+91 94273 01436
Sales: Email :
www.unitechinstrument.com
Website:
“Sure for service with hi-end versal nology”Uni Tech
Sales@unitechinstrument.com
Add.-503/504,Helix Complex , Opp. Surya Hotel, Sayajigunj, Vadodra-05. Gujrat. INDIA, PH-0265 6623551
Model No. : UT-101 F
PAGE:9
REGISTER ADDRESS FOR MODBUS RTU PROTOCOL
zz
SR NO ANALOG PARAMETERS ABSOLUTE ADDRES ACCESS TYPE
1 PROCESS VALUE 40001 READ ONLY
2 DECIMAL POINT 40002 READ ONLY
3 SETPOINT - 1 40003 READ/WRITE
4 SETPOINT - 2 40004 READ/WRITE
5 RELAY 1 STATUS 40005 READ ONLY
6 RELAY 2 STATUS 40006 READ ONLY
CALIBRATION VALUES
zz
*
* Span Calibration at 100ºC
INPUT ZERO-VALUE SPAN VALUE
J - T/C 0100-0600 6000-7800
K - T/C 0800-1000 6000-7800
R - T/C 0800-1000 6000-7800
S - T/C 0800-1000 6000-7800
T - T/C 0800-1000 6000-7800
4 - 20 mA 0100-0600 6000-7800
0 - 20 mA 0100-1000 6000-7800
1 - 5 VDC 0100-1000 6000-7800
10 V DC 0100-1000 6000-8000
PT-100 900-1500 2000-3000
E - T/C 0800-1000 6000-8000
C - T/C 0800-1000 6000-8000

Unitech UT-101 F Specifications

General

Brand	Unitech
Model	UT-101 F
Category	Controller
Language	English
