Replacing Relays
18
Replacing Relays
Should a relay fail, it can be replaced by anyone qualifi ed to solder or work
on electronics. Replacement relays should be available from anywhere
United Spas products are sold.
Relay Locations
K3
K10 - Temp Relay
K20 - Pump-1 Lo-Speed Relay
K30 - Pump-1 Hi-Speed Relay
K40 - Pump-2 Low &
Aux Relay
K50 - Ozone Relay
K2
K6 K5
K7 K4
K9 K1 K10
K60 - Light Relay
K70 - Pump-2 Hi-Speed Relay
K90 - Hi-Limit-L1 Relay
K10 -
Hi-Limit-L2 Relay
