UNITROL MODEL #8000, 8012
CHILLER
INSTALLATION
4
3. Push the ▲ or ▼ to select the desired turn-on
temperature for the chiller. Note that this chiller has been
factory set to allow a minimum temperature of 55ºF.
4. Push and release the SEL button. This will lock in the new
setting.
5. Then push the ▼ button and SEL button at the same
time.
6. Release both buttons. The display will briefly show 00,
and then the tank temperature.
TEMPERATURE
CONTROLLER OPERATION
1. When the water tank is at least 3ºF above the SV
(customer set point), the compressor will start operating.
At this time, a small red square light marked OUT located
just above the SEL button on the controller will glow.
2. When the water tank temperature reaches the SV value,
the compressor will turn off and the red OUT light will stop
glowing.
If any problems are incurred during this installation, contact the
Unitrol service department at 847-480-0115. Please have the
model number and serial number ready.
