UNITROL MODEL #8000, 8012
CHILLER
INSTALLATION
1
1. Carefully remove chiller from the shipping carton and
inspect for external damage. If any damage is seen, do
not continue until a representative of the freight company
views the damage, and a claim to the freight company has
been filed.
2. Install the chiller in a location that will keep the air intake
(front of chiller with air filter) and air exhaust (back of
chiller with expanded metal plate) at least 36” from the
nearest wall. This is required to allow maximum air
movement over the condenser coil.
3. Remove the water tank cover and untie the water level
switch float. Leave the water tank cover off for now.
4. Locate two ¼” NPT bulkhead fittings at the back of the
chiller. Install hose barbs and connect as marked to the
welder. Use Teflon tape on fittings to prevent excessive
force being required on installation and to make a better
seal.
THIS CHILLER IS DESIGNED FOR INSIDE
INSTALLATION. ONLY CHILLERS PURCHASED WITH
THE –OS (OUTSIDE) KIT CAN BE INSTALLED
OUTSIDE IN AREAS WHERE THE AIR TEMPERATURE
CAN FALL BELOW 45ºF, AND SUCH INSTALLATION
WILL VOID THE WARRANTY.
