4/04 IO-LC1, IO-LC3 I/O Expansion Modules

Unitronics Industrial Automation 3

Screw-Mounting

The figure below is not drawn to scale. It may be used as a guide for screw-mounting the module.

Mounting screw type: either M3 or NC6-32.

4mm

5.8mm

(0.228")

85mm

(3.346")

80mm

(3.15")

68.4mm

(2.693")

93mm

(3.66")

4mm (x2)

(0.16")
