6/05 V200-18-E3XB Snap-in I/O Module
Unitronics 15
Table 1: Thermocouple input ranges
Type Temperature range Wire Color
ANSI (USA) BS 1843 (UK)
mV -5 to 56mV - -
B
200 to 1820°C
(300 to 3276°F)
+Grey
-Red
+None
-Blue
E
-200 to 750°C
(-328 to 1382°F)
+Violet
-Red
+Brown
-Blue
J
-200 to 760°C
(-328 to 1400°F)
+White
-Red
+Yellow
-Blue
K
-200 to 1250°C
(-328 to 2282°F)
+Yellow
-Red
+Brown
-Blue
N
-200 to 1300°C
(-328 to 2372°F)
+Orange
-Red
+Orange
-Blue
R
0 to 1768°C
(32 to 3214°F)
+Black
-Red
+White
-Blue
S
0 to 1768°C
(32 to 3214°F)
+Black
-Red
+White
-Blue
T
-200 to 400°C
(-328 to 752°F)
+Blue
-Red
+White
-Blue
Analog Outputs
Number of outputs 4 (single-ended)
Output range 0-10V, 4-20mA. See Note 12.
Resolution 12-bit (4096 units)
Conversion time Synchronized to scan time.
Load impedance 1kΩ minimum—voltage
500Ω maximum—current
Galvanic isolation
Analog outputs to bus Yes
Analog outputs to
Analog/PT/TC inputs
Yes
Analog outputs to analog
outputs
No
Linearity error ±0.1%
Operational error limits ±0.2%
Notes:
12.
Note that the range of each I/O is defined by wiring, jumper settings, and wi
thin the controller’s
software.
Env
ironmental
IP20 / NEMA1
Operating temperature
0° to 45°C (32° to 113°F)
Storage temperature
-20° to 60° C (-4° to 140°F)
Relative Humidity (RH)
5% to 90% (non-condensing)
Dimensions (WxHxD) 138x23x123mm (5.43x0.9x4.84”)
Weight 279g (9.87 oz)
