UNITY LAUNDRY SYSTEMS UTS29 Installation And Maintenance Instructions

7
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
02 SPECIFICATIONS AND DIMENSIONS
2.1 GENERAL SPECIFICATIONS
MOTOR
Size–HP 3.0
CAPACITY
Cylinder Volume – cu. ft. (liters) 8.8 (251.3)
Cylinder Diameter – in. (mm) 30.5 (774)
Cylinder Depth – in. (mm) 21.0 (534)
Dry Load Capacity – lb. (kg) 62 (28.1)
OPERATING SPEED & EXTRACT FORCE
Washing Speed (RPM) 45-50
Maximum Extract Speed (RPM) 277
Maximum Extract Force (G-force) 800
CONNECTIVITY
USB Programmability Yes
DIMENSIONS
Width – in. (mm) 45.4 (1152)
Depth – in. (mm) 40.9 (1038)
Height–in.(mm) 58.4 (1484)
CRATED DIMENSIONS
Width – in. (mm) 44.9 (1140)
Depth – in. (mm) 48 (1220)
Height–in.(mm) 61.1 (1552)
APPROXIMATE WEIGHT
Uncrated – lb. (kg) 1433.2 (650)
Crated – lb. (kg) 1653.5 (750)
ELECTRICAL CONNECTION OPTIONS (VOLTS/Hz/PHASE)
208–240V/50-60Hz/1PH(noelectricalheating) Yes
WATER HEATING OPTIONS
Hot/ColdWaterConnectionsOnly Yes
WATER, CHEMICAL DISPENSING, DRAINS
Number of Water Inlets 3
Inlet Sizes – in. (mm) 1 (25.4)
Number of Dispenser Compartments 4
Number of External Chemical Connections 5
Dump Valve Drain Size – in. (mm) 3 (76.2)
INSTALLATION RECOMMENDATIONS
Minimum Clearance Between Machines - in (mm) 0 (0)
Minimum Clearance in front of Machines - in (mm) 39.4 (1000)
Minimum Clearance Behind Machines - in (mm) 31.5 (800)

UNITY LAUNDRY SYSTEMS UTS29 Specifications

General

Brand	UNITY LAUNDRY SYSTEMS
Model	UTS29
Category	Laundry Appliance
Language	English
