34
Osiris
EMITT - Setting IR Emitter Outputs
The MRF-200 and MRF-300 Base Stations enable you to route or
steer the IR commands from any Device to any or all of the IR
Line Outputs. This allows you to control identical devices using
the exact same IR commands (such as an array of television sets
in a media room or a stack of identical satellite receivers installed
in a central location with one satellite receiver dedicated to each
room with a television). Each button push (or macro step) is rout-
ed to the specific IR Line Output you’ve assigned to a device. In
the factory set default settings, the Osiris is set to route IR com-
mands from any device to ALL IR Line Outputs simultaneously. To
change the Osiris default settings follow these steps:
From the RF Settings Menu, select EMITT.
Decide whether you are changing the Emitter settings for all devices
or just one of the devices of the Osiris.
Select ALL to change the Emitter settings to
ALL devices in the Osiris. Then, go to Step 4.
Select DEVIC to change the Emitter settings to
just one of the devices in the Osiris. Then, go
to Step 3.
1
2
Select the new setting by pressing the desired button, then press SAVE
to save your new setting and return to the RF settings menu.
Displays the current ID#
Change the ID# to a higher number
Change the ID# to a lower number
Save the new setting
Exit this Menu without changing
the IR/RF settings
4
ID #
ID: 0
UP
DOWN
SAVE
EXIT
SELECT
EMITT
ALL
DEVICE
EXIT
SELECT
To Next Page
