Universal Space LANE MASTER - Page 40

Lane Master Manual
07/19/2017
39
9.3 Display Frame
No. Part No. Code No. Name Qty
1 L105-202-000 20211605001 Marquee reinforced board 2
2 L105-209-000 20211605042 Up mid connected plate 3
3 L105-206-000 20211605041 Mid connected plate 2 3
4
L105-207-000
20211605003 Rear R Lane reinforced board 4
L105-139-000 20104000002 Cross recessed hexagon screw kit 16
5 L105-208-000 20211605004 Rear L Lane reinforced board 2 5
6
L105-290-000 26000008000 Cabinet leveller 10
L105-291-000 26000010000 Caster bracket 12
L105-506-000 25501000056 Caster 12
L105-140-000 20104000003 Cross recessed hexagon screw kit 32
L105-152-000 20102030014 Hexagon nut 4
7
L105-204-000 20211605002 Lane reinforced board 6
L105-112-000 20101020036 Cross recessed pan head screw suite 8
8 L105-205-000 20211605040 Mid connected plate 1 1
9 L105-203-000 20211605039 Up mid connected plate 1
10 L105-316-000 20211605061
Connected board
2
11 L105-210-000 20211605005 Up door fixed plate 2
4 L105-207-000 20211605003 Rear R Lane reinforced board 4
