Universal Space LANE MASTER - Page 41

Lane Master Manual
07/19/2017
40
No. Part No. Code No. Name Qty
1 L105-413-000 20311605061 Front up board 2
2 L105-412-000 20311605047 Top board 2
3 L105-411-000 20311605046 Fan board 2
4 L105-410-000 20311605045 Rear up board 2
5 L105-439-000 20311605007 Up door fixed plate 4
6 L105-435-000 20311605056 Up service door 1
7 L105-433-000 20311605055 Back bottom connected plate 2
8 L105-409-000 20311605044 Rear mid board 2
9 L105-423-000 20311605032 Lane board 2
10 L105-437-000 20311605058 Back bottom connected plate 2
11 L105-438-000 20311605006 Door fixed plate 4
12
L105-407-000 20311605030 Bed board 1
L105-145-000 20114000004 Nut 8
L105-148-000 20114000021 Paw nut 36
13
L105-401-000 20311605A001 L side board 1
L105-145-000 20114000004 Nut 20
L105-147-000 20114000009 Nut 4
L105-148-000 20114000021 Paw nut 13
