Buttons and interface location
Rear panel Control
5
HDMI
PC IN
PC
AUDIO IN
Y
Pb/Cb Pr/Cr
AUDIO
L R
COMPONENT IN
AV OUT
AV IN
VIDEO
L R
S-VIDEO
ANT.
Power cable jack
1 2 3 4 6
78
5
HDMI Input Connnect a signal to HDMI/DVI
PC Input
AV
Connect the monitor output connector from a PC to the jack
Component Input Connect a component video/audiodevice to these jacks.
Input Connect audio/video out from an audio/video device to these jacks.
S-Video Input Connect S-Video out from a S-Video device to these jacks.
Earphone jack Earphone Audio output terminal
Antenna Input Connect cable or antenna signals to the TV, either directly or
through your cable box.
Video/Audio output terminal
Connect ordinary video/audio or other appliance audio input terminals.
