USING THE INGREDIENTS CHUTE
The ingredients chute provided with your mixer enables you to add ingredients to the bowl while the
mixer is running and without opening the Swing Ring™ Safety Guard. The chute may be installed on
the front or side of either half of the guard. Once the chute is properly installed, it can remain in place
permanently, if desired.
INGREDIENTS CHUTE INSTALLATION
Slide the bottom of the chute between horizontal safety guard rings and engage the chute onto the safety
guard.
INGREDIENTS CHUTE
FIGURE 2
BOWL DOLLIES AND ADAPTER
Bowl dollies (Figure 3 [H]), available for the 60 quart bowl and the 30 for 60 quart bowl, simplify
moving large, heavy batches to the next location. To remove heavy batches of dough from the mixer,
first place the bowl dolly under the bowl. Then open the bowl clamps (Figure 1 [19]) and lower the bowl
onto the bowl dolly. Be sure the bowl support pins clear the bowl mounting ring before moving the
bowl and dolly.
A bowl dolly adapter (Figure 3 [I]) is available to use the 60 quart bowl dolly with a 30 quart bowl.
USING A SMALLER BOWL
For maximum flexibility, a 30 quart bowl is available for use on the SRM60+ mixer. Specially sized
agitators must be used. See (Figure 3) on page 11 for the part numbers for these parts.
SPLASH / EXTENSION RING
A splash/extension ring (Figure 3 [J]) mounted to the bowl helps confine ingredients during the mixing
of certain recipes. Never use the ring to overload the bowl. Consult the Table of Mixing capacities
Figure 4 on page 12 for appropriate loads.
NOTE: Overloading the mixer beyond the factory specifications can damage the mixer and will void
the warranty.
Page 7
