Unverferth 7250/8250/9250 — Parts
5-3
Please visit www.unverferth.com/parts/ for the most current parts listing.
Final Assembly
PAINT SPRAY
Black 9000533
Green 9001791
Red 9002197
Primer,Gray 9000592
Touch-Up Paint
ITEM DESCRIPTION PART NO. QTY NOTES
12
Hose Tube, Plastic - 63” 251389 1 Models 7250 & 8250
Hose Tube, Plastic - 96” 234210 1 Model 9250
13 Hose Clamp, 3” TA800922 1
14 Rod, Indicator
250776B
1
Models 7250 & 8250
267070B Model 9250
15 Arm, Indicator 250777B 1
16 Spring, Indicator 92971B 1
17 Mount 250778 1
18 Plate 9-2075 1 Model 9250
19 Pipe 7-0345 2
20 Hitch See Page 5-4 1
21 PTO See Page 5-21
22 Jack Assembly
9003299
1
Models 7250 & 8250
9003295 Model 9250
23 Axle Assembly
See Pages 5-5
& 5-6
1
24 Wheels See Page 5-10 -
25 PTO Shield
250192B
1
Models 7250 & 8250
265184B Model 9250
26 Pad, PTO Shield 9001496 1 11 x 13 3/4
27 Pad, Runner 9001497 2 2 7/8 x 7
28 Screen Weldment N/A -
29 Transport Chain
94098
1
Model 7250
9003278 Models 8250 & 9250
30 Guard 251086B 1
31
Capscrew 3/8-16UNC x 1 9390-055 3
Flat Washer 3/8 9405-076 3
Locknut 3/8-16UNC 9928 3
32 Pipe, PTO Guard
251049
1
50 1/2” - Models 7250 & 8250
251163 33 1/8” - Model 9250
251164 50 1/4” - Model 9250
33 Storage Box 9005850 1
34 Capscrew 1/4-20UNC x 1 1/4 9390-006 2 Grade 5
35 Flat Washer 1/4” 9405-064 4
36 Fender Washer 94763 2
37 Locknut 1/4-20UNC 9936 2
(August 2015)
Please visit www.unverferth.com/parts/ for the most current parts listing.
To Next Page
