Climate Control Zoning System II instruction sheet l 5
Wiring diagram
Important! This instruction sheet serves as a
reminder for experienced installers. Uponor strongly
recommends using the full installation and operation
manual for complete installation details.
Pump relay
Boiler/heat source
24
VAC
24 VAC
>
15.75"
(40 cm)
Thermostat operating instructions
Wireless Digital
Thermostat (A3800167)
Wireless Dial
Thermostat (A3800165)
