Safety instructions
This quick start guide to serves as a reminder for
experienced installers. We strongly recommend reading
the full manual before installing the control system.
Controller
The Uponor system uses 50 Hz, 230 V AC
power. In case of emergency, immediately
disconnect the power.
Electrical installation and service behind
secured 230 V AC covers must be carried
out under the supervision of a qualified
electrician.
The transformer module is heavy and might
detach if the controller is held upside down
without the cover on.
To avoid interference, keep installation/data
cables away from power cables of more than
50 V.
If communication difficulties exist, Uponor
recommends relocating the antenna to a more
optimal position, and not installing Uponor
radio sources to close to each other (at
least 40 cm apart), for solving exceptional
problems.
Ensure that each actuator is connected to the
correct channel so that the thermostats are
controlling the correct loops.
NOTE!
Wires between transformer and controller card
needs to be disconnected prior to detaching.
NOTE!
Connect only one actuator for each channel.
Channels 01 and 02 have double outputs (a
and b) for two actuators.
Thermostat/System device
NOTE!
Registration of at least one thermostat must
be done before registering a system device.
NOTE!
Up to four controllers can be registered to an
interface.
If more than one controller is available in the
system, register the thermostat as a system
device to the master controller.
The switches in public the thermostat must
be set before the thermostat is registered.
The switches, in the public thermostat, must
be set to one of the available functions,
otherwise it cannot be registered.
Thermostatic Head
NOTE!
The thermostat in control of the thermal
heads should not also control under floor
heating. Make notes to make sure
NOTE!
If two thermostatic heads already have been
registered to a channel, register the third to
the next channel in line. If more thermostat
channels are needed they can be added in
thermostat registration mode.
NOTE!
There is no indication showing if a
thermostatic head already is registered to a
channel.
The thermostatic head must be installed on
a radiator before registering it to a controller.
Because the thermostatic head will perform a
valve stroke calibration, when registered, to
accurately operate the valve on the radiator.
UPONOR SMATRIX WAVE · QUICK GUIDE
