Uponor X-163

Register thermostat or system device to
a controller
NOTE!
Registration of at least one thermostat must
be done before registering a system device.
To register room thermostats and system devices (timer
etc.) to the controller:
1. Press and hold the OK button on the controller, for
about 3 seconds, until the LED for channel 1 (or the
fi rst unregistered channel) fl ashes red.
2. Actuator channel selection
2.1 Use buttons < or > to move the pointer (LED
fl ashes red) to a preferred channel.
2.2 Press the OK button to select the channel for
registration. The LED for the selected channel
starts fl ashing green.
2.3 Repeat steps 2.1 and 2.2 until all channels to
be registered with the thermostat are selected
(LEDs fl ashing green).
Note! It is recommended to register all channels
to the thermostat at the same time.
3. Thermostat registration
Thermostat T-163, with various functions
3.1 Gently press and hold the registration button
on the thermostat, release when the LED starts
fl ashing green (located in the hole above the
registration button).
The selected channel LED in the controller turns
fi xed green and the registration is complete.
Thermostat T-165
3.1 Gently press and hold the registration button
on the thermostat, release when the LED on the
front of the thermostat starts fl ashing.
The selected channel LED in the controller turns
fi xed green and the registration is complete.
Thermostats T-166 and T-168
3.1 Press and hold both - and + buttons on the
thermostat until the text CnF (confi gure) and a
communication icon is displayed.
The selected channel LED in the controller turns
fi xed green and the registration is complete.
4. Repeat steps 2 and 3 until all available thermostats
are registered.
5. System device channel selection
5.1 Use buttons < or > to move the pointer to the
power LED (LED fl ashes red).
5.2 Press the OK button to enter system channel
registration mode. The power LED fl ashes
according to the pattern long blink, short pause,
long blink and channel 1 LED fl ashes red.
5.3 Select a system channel, see list below.
1 = Timer
2 = Relay module
3 = Public thermostat with outdoor sensor
4 = Public thermostat with heating/cooling
switch from contact or heating cooling
switch from sensor input
5 = Public thermostat with Comfort/ECO switch
5.4 Press the OK button to select system device
channel. The channel LED starts fl ashing green
6. System device registration
Timer I-163
6.1 Press and hold both - and + buttons on the
thermostat until the text CnF (confi gure) and a
communication icon is displayed.
The selected channel LED in the controller turns
fi xed green and the registration is complete.
Thermostat T-163 as a system device, with
various functions
6.1 Gently press and hold the registration button
on the thermostat, release when the LED starts
fl ashing green (located in the hole above the
registration button).
The selected channel LED in the controller turns
fi xed green and the registration is complete.
Relay module M-161
6.1 Press and hold the register button on the relay
module until the LEDs on the module start
fl ashing slowly.
The selected channel LED in the controller turns
fi xed green and the LEDS on the relay module
start fl ashing fast again, to turn off a few
seconds later.
7. Repeat steps 5 and 6 until all available system
devices are registered.
8. End registration
Press and hold the OK button on the controller, for
about 3 seconds, until the green LEDs turn off to
end registration and return to run mode.
