Unregister one channel or system device
When a channel or system device is inaccurately
registered or if a thermostat registration needs to be
redone, it is possible to remove the current registration
from the controller.
To unregister a channel:
1. Enter registration mode. Channel 1 LED fl ashes red/
green, or the fi rst unregistered channel fl ashes red.
2. If a system device (interface etc) is to be
unregistered, enter system channel registration
mode. The power LED fl ashes according to the
pattern long blink, short pause, long blink and
channel 1 LED fl ashes red/green.
3. Use buttons < or > to move the pointer (LED
fl ashes red) to the selected channel (fl ashes green if
registered) to unregister.
4. Press the < and > buttons simultaneously until the
LED for the selected channel starts fl ashing red
(about 5 seconds).
Unregister all channels
When one or more channels (thermostats and system
devices) are inaccurately registered, it is possible to
remove all registrations at the same time.
To cancel all channel registrations:
1. Enter registration mode. Channel 1 LED fl ashes red/
green, or the fi rst unregistered channel fl ashes red.
2. Press the < and > buttons simultaneously until the
LEDs for all channels except one turn off (about
10 seconds). The one remaining fl ashes red.
Miscellaneous functions
See full manual for more information about
Autobalancing of actuators (eliminating the need of
manual balancing,on by default), Cooling, and Comfort/
ECO settings etc.
Technical data
General
IP IP20 (IP: degree of inaccessibility to active parts of the product
and degree of water)
Max. ambient RH (relative humidity) 85% at 20 °C
Thermostat and timer
CE marking
Low voltage tests EN 60730-1* and EN 60730-2-9***
EMC (electromagnetic compatibility requirements) tests EN 60730-1 and EN 301-489-3
ERM (electromagnetic compatibility and radio spectrum matters) tests EN 300 220-3
Power supply Two 1.5 V AAA alkaline batteries
Voltage 2.2 V to 3.6 V
Operating temperature 0 °C to +45 °C
Storage temperature -10 °C to +65 °C
Radio frequency 868.3 MHz
Transmitter duty cycle <1%
Connection terminals (thermostats only) 0.5 mm² to 2.5 mm²
Antenna
Power supply From controller
Radio frequency 868.3 MHz
Transmitter duty cycle <1%
Receiver class 2
