28
BASE INSTALLATION WITH LOWER ANCHORS
CONTINUE IF USING PREFERRED LOAD LEG INSTALLATION
INSTALLING LOAD LEG
1 After the base is secured, rotate load leg
extension until its showing fully GREEN.
2 Using two hands, separate the two ends to
remove any RED showing.
NOTE: After installing the load leg, check
the level angle indicator on base to ensure
the bubble is still within the lines.
REVIEW SAFETY CHECK ON PAGE 30.
All steps must be achieved.
1
2
To Next Page
