65
GENERAL USE – Safety Check
• This child restraint is for rear-facing use only.
• The seat must be tightly installed in a forward-facing vehicle seat.
• Minimum 1" (2.5 cm) gap between the child's head and top of headrest
A
.
• Harness should be at the shoulders or 1-2 positions below
B
.
• Retainer clip must be at armpit level and harness straps should be snug
C
.
• The top of child’s head should not be less than 1" (2.5 cm) from the top of the headrest when in its highest position.
• The child must weigh between 4 and 30 lbs (1.8 and 13.6 kg) and be no taller than 30" (76.2 cm).
• The back seat is the safest place for children aged 13 and under.
• NEVER use non-regulated products with this child restraint, unless approved by UPPAbaby.
• NEVER place in front of an active airbag.
• Install using lower anchor or the vehicle seat belt, not both.
• DO NOT secure an infant in the carrier with extra material, bulky clothing, or extra padding. Instead place
a blanket over the harness after properly securing the child
D
.
• The carry handle must be locked in the (5th) rebound position when in use in a vehicle.
• While in vehicle, the canopy can be fully extended or in storage compartment.
• Adjust base to the appropriate angle by using the angle indicator on the sides of the base or the level to
ground line on the carrier.
• Always check the tightness indicator is GREEN after each use.
• Always secure an unoccupied child restraint; in a crash an unsecured infant car seat may injure occupants
in your vehicle.
A
B
C
D
1"
