37
3 While holding the shoulder belt firmly, check the indicator.
If GREEN, close the top of the lock-o over the lap/shoulder
belt.
NOTE: Tightness indicator should be GREEN.
4 Push the bottom of the lock-o all the way down until you
hear an audible click.
NOTE: Anti-Rebound+ Panel must make full contact with
the seat back. If it does not make full contact, refer to the
Waterfall note (page 41).
LOAD LEG INSTALLATION CONTINUE TO PAGE 40.
REVIEW SAFETY CHECK ON PAGE 42.
All steps must be achieved.
BASE INSTALLATION WITH VEHICLE SEAT BELT
Lap/Shoulder Routing Method
3
4
