39
3 While holding the excess lap belt webbing, firmly check the
indicator. If GREEN, close the top of the lock-o over the
vehicle belt.
NOTE: Tightness indicator should be GREEN.
4 Push the bottom of the lock-o all the way down until you
hear an audible click.
NOTE: Anti-Rebound+ Panel must make full contact with the
seat back. If it does not make full contact, please refer to the
Waterfall note (page 41).
LOAD LEG INSTALLATION CONTINUE TO PAGE 40.
REVIEW SAFETY CHECK ON PAGE 42.
All steps must be achieved.
BASE INSTALLATION WITH VEHICLE SEAT BELT
Lap Belt Only Routing Method
3
4
To Next Page
