US Blaster USB 1380 - Page 25

4 CHANNEL SPEAKER WIRING DIAGRAM
CH4 CH3
CH2 CH1
BRIDGED
BRIDGED
FUSE
POWER
REM
+12V
GND
PROT
ON
SPEAKER OUTPUT
4-8 Ohms
2CH 1CH
2 SPEAKER BRIDGED
CH4 CH3
CH2 CH1
BRIDGED
BRIDGED
FUSE
POWER
REM
+12V
GND
PROT
ON
SPEAKER OUTPUT
2SPEAKER+1SUBWOOFERS
2-4 Ohms
SUB WOOFER
3CH
4-8 Ohms
1CH
2CH
2-4 Ohms
CH4 CH3
CH2 CH1
BRIDGED
BRIDGED
FUSE
POWER
REM
+12V
GND
PROT
ON
4 SPEAKER STEREO
SPEAKER OUTPUT
2-4 Ohms
3CH
1CH 4CH 2 CH
CH4 CH3
CH2 CH1
BRIDGED
BRIDGED
FUSE
POWER
REM
+12V
GND
PROT
ON
6 SPEAKER HEX MODE
SPEAKER OUTPUT
4-8 Ohms
6CH
4-8 Ohms
5CH
4-8 Ohms 4-8 Ohms
4CH
3CH
1CH
4-8 Ohms
2CH
Fig.5
10
