US Blaster USB 1380 - Page 82

BRIDGED
CH5
SPEAKER OUTPUT
FUSE
GND
REM
+12V
ON
PROTECTION
POWER
CH3/CH1
CH4/CH2
CH5
BRIDGED
CH5
SPEAKER OUTPUT
FUSE
GND
REM
+12V
ON
PROTECTION
POWER
CH3/CH1
CH4/CH2
CH5
Fig.5
4-8 Ohms
2CH1CH
4-8 Ohms
5CH
1CH
4-8 Ohms
2CH
2-4 Ohms
3CH
BRIDGED
CH5
SPEAKER OUTPUT
FUSE
GND
REM
+12V
ON
PROTECTION
POWER
CH3/CH1
CH4/CH2
CH5
2-4 Ohms
1CH2CH
2-4 Ohms
4CH 3CH
2-4 Ohms
5CH
4-8 Ohms
6CH
4CH
4-8 Ohms
3CH
2-4 Ohms
7CH
S
CHEMA DI COLLEGAMENTO DEGLI ALTOPARLANTI PER L’IMPIANTO A CINQUE CANA
LI
2 ALTOPARLANTI (A PONTE) + 1 SUBWOOFER
4 ALTOPARLANTI + 1 SUBWOOFER
CONFIGURAZIONE HEX + 1 SUBWOOFER
