13
Key Part No. Description Qty.
1 69427B Ash Pan 1
2 40487 Ash Dump Cover 1
3 24103 ½ Firebrick 2
4 89066 Full Firebrick 17
5 69429 Feed Door 1
N/S AC0600 Feed Door Gasket & Silicone 1
6 PL8535-01 Door Handle 1
7 891135 Spring Handle (Nickel) 1
8 AC09185 Door Barrell/Roller Ball/Pin Assy. 1
9 891108 Door Glass 1
N/S 88087 Door Glass Gasket 6 ft.
10 891114 Top Window Bracket 4
11 PL02715 Bottom Window Bracket 1
12 83033 Machine Screw 8-32 X ¼ 12
13 891213 Hinge Pad 1
N/S 83274 Nut
3
/8-16 2
N/S 83045A Washer 2
14 25298 Bafe 1
15 891759 Hearth Trim - Nickel 1
16 83431 Weld Tab 3
17 25307 Flue Collar 1
18 88042 Gasket, Flue Collar 2 ft.
19 D6 Cast Iron Damper 1
N/S 891492 Blower Assembly 1
To Next Page
