UTC Fire and Security Interlogix ATS1235 User Manual

2 / 32 P/N 1070346 • REV 5.0 • ISS 03OCT11
5
ATS1235.VXX
0-Exit, Menu: _

1-DGP Status
0-Exit, Menu: _
 Det. Supervision:
*=-, #=+, 0=Exit
 Det. Low Battery:
*=-, #=+, 0=Exit
 Smoke Det. Dirty:
*=-, #=+, 0=Exit

2-Program Zones
0-Exit, Menu: _
 Zones (17-32): 17 Unused
0=Exit No: 17
 Press Program Switch
0 = Exit

3-View RF Devices
0-Exit, Menu: _
 Zone number (17-32)?
0=Exit: 17
 17: AB2230: DWS
*-Prev, 0-Exit

4-View Zone Status
0-Exit, Menu: _
 Zone number (17-32)?
0=Exit: 17
 17: Normal
*-Prev, 0-Exit

5-View Signal Level
0-Exit, Menu: _
 Zone number (17-32)?
0=Exit: 17
 17: -40 dB [III ]
*-Prev, 0-Exit

6-Program Fob
0-Exit, Menu: _
 Fob No. (1-16)
0=Exit: 1
 Press Program Switch
#=Exit

1-User, 2-Relay
Option: 1
 Button Set 1
User No: 2
7-View Fobs
0-Exit, Menu: _
 Fob Not Used
*-Prev, 0-Exit
If programmed: User 2, ****, F554EC
*-Prev, 0-Exit

8-Short Supervsn Time
0-Exit, Menu: _
 (0-32) 0 Hours
Hours: _
 (0-59) 20 Minutes
Minutes: _

9-Long Supervsn Time
0-Exit, Menu: _
 (0-32) 2 Hours
Hours: _
 (0-59) 0 Minutes
Minutes: _

10-Smoke Supervsn Time
0-Exit, Menu: _
 (0-32) 4 Hours
Hours: _
 (0-59) 0 Minutes
Minutes: _

11-Supervsn Options
0-Exit, Menu: _
 17: Supervsn On
*=Change, #-Enter
 17: Relay 17 Disabled
*=Change, #-Enter
 17: Supervsn Off
*=Change, #-Enter

12-Receiver Sensitivity
0-Exit, Menu: _
 Sensitivity Low (-6 dB)
0-Exit *=Change
 Sensitivity Normal
0-Exit *=Change

13-DGP Settings
0-Exit, Menu: _
 Extended: 16 Zones
*=Change, #-Enter
 Standard: 13+3 Zones
*=Change, #-Enter

Extended: 32 Zones
*=Change, #-Enter
 Standard: 29+3 Zones
*=Change, #-Enter
14-Factory Defaults
0-Exit, Menu: _
 Set Defaults?
*=Yes, #=No:
