UTEK ULTRALOQ - Installation Guide; Installation Video; Preparing Door

Installation Guide
Installation Video
- 3 -
1. Preparing Door
Check the door’s dimensions.
Step 1
Measure to confirm that the door is between 1
3
/
8
” ~ 1
3
/
4
”
(35 mm-45 mm) thick.
If your door is thicker than
1
3
/
4
” , please visit support.u-tec.com
to get help.
Step 2
Measure to confirm that the diameter of the hole is 2
1
/
8
” (53
mm) or
1
1
/
2
” (38 mm)
Step 3
Measure to confirm that the backset is either 2
3
/
8
” or 2
3
/
4
”
(60 mm or 70 mm).
Step 4
Measure to confirm that the diameter of the hole in the door
edge is
1” (25 mm).
Step 5
Measure to confirm the depth of the hole in the frame is at least
1''(25 mm).
If you have a new door, please drill the holes according to Drill
Template.
Please scan this QR code to watch the easy
step by step installation video before
attempting to install ULTRALOQ.
Or you can also view the webiste directly.
www.u-tec.com/lock/Bolt_F_WiFi/guide
1”
25 mm
53 mm
(35 mm ~ 45 mm)
1
3
/
8
” ~ 1
3
/
4
”
2
3
/
4
”
2
3
/
8
”
(70 mm)
OR
(60 mm)
38mm
1
1
/
2
”
1''(25 mm)
2
1
/
8
”
