SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install the
product. SAVE THESE INSTRUCTIONS IN A LOCATION CLOSE TO YOUR LIGHT FIXTURE SO
YOU CAN REFER TO THEM AT A LATER TIME.
the new one.
• LED electronics can be damaged by electrostatic discharge (ESD) shock. Before installation,
discharge yourself by touching a grounded bare metal surface to remove this hazard. To avoid damage,
do not remove the clear lens over the LED module.
•
DO NOT USE THIS FIXTURE WITH A DIMMING CIRCUIT. If you currently have dimmer controls, you
will need to remove them and replace them with regular electrical switches. If you have a three-way
dimmer, you will have to replace it with a regular three-way switch. If you are unfamiliar with electrical
WARNING
CAUTION
PACKAGE CONTENTS
HARDWARE CONTENTS
PARTS DESCRIPTION QUANTITY
A LED Head 2
B Sensor Arm 1
PARTS DESCRIPTION QUANTITY
C Sensor Head 1
D Wall Plate 1
Lowes.com
2
GG
A
D
B
C
Machine
Screw
Qty. 2
Long
Machine
Screw
Qty. 1
Silcone
Cap
Qty. 1
Foam Gasket
(Not shown
to size)
Qty. 1
GND
FRONT
To Next Page
