INSTALLATION INSTRUCTIONS FOR ROUND SURFACE MOUNT ELECTRICAL BOXES
2. Remove the protective paper barrier from the adhesive
face of the foam gasket (GG). Trace the supply wires through
the openings in the gasket and adhere the gasket to the
mounting strap and outer edge of the round surface mount
electrical box.
4. Position the wall plate over the mounting strap so the
center hole of the wall plate aligns with the center hole in
the mounting strap. While holding the wall plate in place, put
the long machine screw (EE) through the center hole of the
wall plate and mounting strap. Tighten the screw properly to
secure the wall plate onto the electrical box. NOTE: Make
sure the gasket (GG) properly seals the gap between the
wall plate and the electrical box to prevent water seepage
into the electrical box.
Hardware Used
Lowes.com
Long
Machine Screw
x 1
EE
4
Hardware Used
Wire Nut
x 3
DD
properly grounded. If unfamiliar with the methods of properly
electrical box is made of plastic and/or has a green or bare
the electrical box ground wire should be connected together
using one of the small wire nuts (included). If the electrical
box is made of metal and already grounded, secure the bare
“GND” using the green grounding screw. Connect the
is connected to the white supply lead. Tighten the wire nuts
properly to prevent them from coming loose. If needed, use
electrical tape to secure the wire nuts onto the wire leads.
Push the excess wires back into the electrical box.
head with the adjustment controls and drain holes
facing downward to prevent water damage. The
position of the sensor head should not exceed 45
degrees from horizontal.
Hardware Used
3
DD
DD
2
GG
Foam Gasket
x 1
GG
4
EE
45°
45°
45°
45°
5
To Next Page
