Utilitech UT-IO-70C User Manual

6
ASSEMBLY INSTRUCTIONS
3. Determine mounting conguration to use based
on the mounting hole pattern on the back of at
panel TV (not included).
2. Remove monitor plate (E) from mounting arm (A).
1. Remove two mounting arm screws (PP) from
mounting arm (A) and save them for later use.
2
E
A
11.8 in.
15.7 in.
11.8 in. 15.7 in.
11.8 in.
15.7 in.
15.7 in.
11.8 in.
3 in.
3.9 in.
7.9 in.
7.9 in.
3 in.
3.9 in.
7.9 in.
3
2
1
1
PP
A
Hardware Used
PP
x 2
Mounting arm screw
M4 x 12
Screw
Qty. 4
AA
M6 x 15
Screw
Qty. 4
CC
M8 x 15
Screw
Qty. 4
8 mm Lag bolt
Qty. 2
Anchor
Qty. 2
DD
M4 x 30
Screw
Qty. 4
EE
M6 x 30
Screw
Qty. 4
GG
M8 x 30
Screw
Qty. 4
HH
KK
5 mm
Spacer
Qty. 4
Mounting arm screw
(preassembled to
Mounting arm (A))
Qty. 2
LL
RR
PP
10 mm
Spacer
Qty. 4
MM
8 mm
Steel
washer
Qty. 8
NN
M6 x 12
Carriage Screw
Qty. 8
OO
II
JJ
FF
M8 x 50
Screw
Qty. 4
M6 Nut
Qty. 8
Wrench
Qty. 1
QQ
6 mm
Steel
washer
Qty. 4
