ENGLISH
DISPLAY DATA DESCRIPTION DEFAULT
MEMO
DATA
AUS Auxiliary channel
tiM - Time working 1’00
biSt - Bistable working
Mon - Monostable working
LP.PA no/Si Flashlight in pause no
St.rt Operation modes StAn
StAn - Start inputs from terminal board are disabled
no - Standard operation
AP.CH - Separated opening and closing commands
PrES - Manned operation
oroL - Timer operation
StoP STOP input no
no - STOP input not available
invE - STOP command stops the gate: START command starts moving in the opposite direction
ProS - STOP command stops the gate: pressing the START command gate continues the motion
Fot 1 PHOTO 1 input no
APCh - Input is available for the connection of the photocell
no - Not available
Fot 2 PHOTO 2 input CFCh
CFCh - Photocell is active in closing and also when the gate is still
no - Not available
Ch - Photocell is active during the closing
Ft.tE no/Si Test of operating of the photocells: no
CoS1 Input safety edge 1 (fix edge) no
no - Non-active input
AP - Input active only in opening
APCH - Input active both in opening and closure
CoS2 Input safety edge 2 (mobile edge) no
no - Non-active input
CH - Input active only in closure
APCH - Input active both in opening and closure
Co.tE Test of operating of the safety edges: no
no - Test disabled
Foto - Test enabled for optical type safety edges
rESi - Test enabled for resistive rubber safety edges
W.L. - Test enabled for wireless edge system
FC.En no/Si End of stroke inputs Si
EnCo no/Si Encoder Input no
S.EnC 0 ÷ 7 Encoder sensitivity 0
i.Adi no/Si Enabling the ADI device no
ASM 0.5” ÷ 1.0’ Anti-skid function 1.0”
no - Function disabled
FinE End of programming no
no - It does not exit from the program menu
Si - It exits from the program menu by storing the setup parameters
PD18 FUNCTION TABLE
