VAC V200 - 5 Dimension; V200 P;E Std

V200 POSITIONER
www.vacaccessories.com
92026r15
23
13/32"
10
Hex size
6 13/16"
173,4
4 3/4"
121
1 25/32"
45
1 25/32"
45
1 5/8"
41
3/16"
5
2 13/32"
61
2 11/16"
68
8 3/16"
208
Gauges 1/8" NPT(4x) (optional)
1/2"
12,5
25/32"
20
31/32"
25
1 7/8"
47,5
Conduit Entry 1/2" NPT (2x)
1 19/32"
40,5
7/8"
22,5
1 9/16"
39,5
2 1/16"
52,5
1 3/16"
30
3/16"
5
1 3/8"
35
Air connections 1/4" NPT (5x)
5/8"
15,5
2 15/32"
62,5
3 27/32"
97,5
1/16"
1,5
1 7/8"
47,5
2 1/4"
57
31/32"
25
2 7/32"
56
2 31/32"
75
5 1/4"
133
5"
127
Dome Indicator(optional)
Conduit Entry 1/2" NPT (2x)
1 13/32"
35,4
ISOF05
Sqr
2 31/32"
75,6
Sqr
2 15/16"
75
4 1/4"
108
1 31/32"
50
2 11/32"
59,7
2 1/4"
57,2
Westlock
Sqr.
Westlock (4x)
UNC 5/16" - 1/2"[12mm
ISO F05 (4x)
M6 - 1/2"[12mm]
Dimensional Drawing VAC Positioner V200 P and E
5. DIMENSIONS
5.1 V200P/E std
