VAC V200FF - Main Supply Filter for IP Converter

V200 POSITIONER
www.vacaccessories.com
92076r16
7
1
2
3
4
2
2.3 Main supply lter for IP converter
Changing the lter
1. Turno󰀨ordisconnectthemainairsupply.
Should air supply not be disconnected or
 turnedo󰀨,thepressuremaycausethe 
 ltercovertoejectfromtheunit.
2. Loosenthescrew(1)andremovelter 
cover(2)
3. Cautiouslyremovethelter(3)witha 
sharp pointed object e.g. a pocket knife.
4. Pressthenewlter(3)intothehousing.
5. Check the O-ring(4) and replace if
needed.
5. Installtheltercover(2)andtightenthe 
screw(1)
If the lter(3) shows traces of
oil or water, check the water/oil
separator in the supply line.
Oil and water can cause
functional problems in
the IP converter.
