Vacmaster EasyClean SCA0801 - Unpacking and Product Features; Assembly

7
GB
NOTE:
A Phillips screwdriver is required.
1. Loosen the pre-attached screw located on the hose storage clip. Secure the hose storage clip onto
the carpet cleaner body with the supplied screw (Fig. 1).
2. Select the preferred attachment and slide it onto the end of the suction hose until it clicks into
place (Fig. 2).
To remove: Press the tool release button and pull away the attachment.
NOTE:
Clip the suction hose with the tool attached into the hose storage clip when not in use
(Fig. 3).
3. Wrap the power cord loosely around the quick release cord hooks (Fig. 4).
• Before starting work, the operating staff must be informed on
- use of the carpet cleaner,
- risks associated with the material to be picked up,
- safe disposal of the picked up material.
1 Power Button 9 Power Cord Hooks
2 Tool Release Button 10 Clean Water Tank
3 Hose Storage Clip 11 Clean Water Inlet Cap
4 Suction Hose 12 Tough Stain Nozzle
5
Dirty Water Tank 13 Wide Path Nozzle
6 Dirty Water Tank Cover Release 14 Carpet Solution
7
Carry Handle 15 Instruction Manual
8 Power Cord
UNPACKING AND PRODUCT FEATURES
ASSEMBLY
