6.1.1.8 Terminal sizes, NXI_xxxx 6
Frame Type
IL
[A]
DC supply terminal Motor cable Terminal
NXI_0125 6 125
NXI_0144 6 144
NXI_0170 6 170
NXI_0208 6
FI9
208
40
13
35
16
PE: M8×25
6 x 40
13
38
17
NXI_0261 6 261
NXI_0325 6 325
NXI_0385 6 385
NXI_0416 6
FI10
416
40
13
50
16
PE: M8×25
6 x 40
13
38
17
NXI_0460 6
460
NXI_0502 6
502
NXI_0590 6
590
NXI_0650 6 650
NXI_0750 6 750
NXI_0820 6
FI12
820
40
13
50
16
PE: M8×25
6 x 40
13
38
17
NXI_0920 6 920
NXI_1030 6 1030
NXI_1180 6
FI13
1180
40
13
50
16
PE: M8×25
6 x 40
13
38
17
Table 6-7. Terminal sizes for Vacon NX_5
