7.3.3 Keypad control menu (M3)
In the Keypad Control Menu , you can choose the control place, edit the frequency reference and
change the direction of the motor. You can enter the submenu level by pressing
Menu button right .
7.3.3.1 Selection of control place
There are three different places (sources) where the inverter can be controlled from. For each
control place, a different symbol will appear on the alphanumeric display:
Control place Symbol
I/O terminals
Keypad (panel)
Fieldbus
You can change the control place by entering the edit mode with
Menu button right . The options can
then be browsed with the
Browser buttons . Select the desired control place with the enter button.
See the diagram on the next page.
See also Chapter 7.3.3. above.
NOTE! There are some special functions that can be performed in menu M3:
Select the keypad as the active control place by pressing
start
for 3 seconds when
the motor is running. The keypad will become the active control place and the current
frequency reference and direction will be copied to the keypad.
Select the keypad as the active control place by pressing
stop
for 3 seconds when
the motor is stopped. The keypad will become the active control place and the current
frequency reference and direction will be copied to the keypad.
Copy the frequency reference set elsewhere (I/O, fieldbus) to the panel by pressing
enter
for 3 seconds.
Note that if you are in any other than menu
M3 these functions will not work.
If you are in some other than menu
M3 and try to start the motor by pressing the START
button when the keypad is not selected as the active control place, you will get an error
message:
Keypad Control NOT ACTIVE .
I/O term
Keypad
Bus/Comm
