Vacon NX OPTCP - Default Chapter; Table of Contents

2 • vacon
Tel. +358 (0)201 2121 • Fax +358 (0)201 212 205
2
INDEX
Document code: DPD00895A
Last edited: 27.01.2012
1. Introduction ....................................................................................................................... 3
2. Ethernet board technical data ............................................................................................ 4
2.1. Overview .................................................................................................................................... 4
2.2. LED indications ......................................................................................................................... 5
2.3. Ethernet .................................................................................................................................... 6
2.4. Connections and wiring ............................................................................................................. 7
3. Installation ......................................................................................................................... 8
3.1. Installing the Ethernet Option Board in a Vacon NX Unit ......................................................... 8
3.2. NCDrive ................................................................................................................................... 10
3.3. IP Tool NCIPConfig .................................................................................................................. 10
3.4. Example with Siemens PLC .................................................................................................... 14
4. Commissioning ................................................................................................................ 23
4.1. Expander board menu (M7) ..................................................................................................... 23
4.2. Profinet parameters................................................................................................................ 23
4.3. IP Address ............................................................................................................................... 23
4.4. Start-up test ............................................................................................................................ 24
5. Profinet IO ........................................................................................................................ 25
5.1. Vendor profile .......................................................................................................................... 25
5.2. Bypass profile ......................................................................................................................... 30
5.3. Profidrive profile ..................................................................................................................... 31
5.4. Parameter channel ................................................................................................................. 35
5.5. Parameter data transfer examples ........................................................................................ 39
6. APPENDIX ........................................................................................................................ 40
