APPENDIX vacon • 41
24-hour support +358 (0)40 837 1150 • Email: fieldbus@vacon.com
1
Multipurpose control application
Data
Value
Unit
Scale
Reference Speed Reference % 0.01%
ControlWord Start/Stop Command
Fault reset Command
- -
Process Data IN1 Torque Reference % 0.1%
Process Data IN2 Free Analogue INPUT % 0.01%
Process Data IN3 Adjust Input % 0.01%
PD3 – PD8 Not Used - -
PID control and Pump and fan control applications
Data
Value
Unit
Scale
Reference Speed Reference % 0.01%
ControlWord Start/Stop Command
Fault reset Command
- -
Process Data IN1
Reference for PID control-
ler
% 0.01%
Process Data IN2 Actual Value 1 to PID con-
troller
% 0.01%
Process Data IN3 Actual Value 2 to PID con-
troller
% 0.01%
PD4–PD8 Not Used - -
