Installation vacon • 9
24-hour support +358 (0)40 837 1150 • Email: fieldbus@vacon.com
1
Install EtherNet option board in slot D or
E on the control board of the frequency
converter. Make sure that the grounding
plate (see below) fits tightly in the
clamp.
Make a sufficiently wide opening for
your cable by cutting the grid as wide as
necessary.
Close the cover of the control unit and
the cable cover.
