1. Vacuum Gauge - Indicates the vacuum pressure level
inside the chamber.
2. “Cooling” Light - Illuminates when adjusting the cooling time.
It also illuminates during the cooling process.
3. “Sealing” Light - Illuminates when adjusting seal time.
It also illuminates during the sealing process.
4. “Gas” Light - This unit does not have a gas flush option.
Set to 0.0 seconds.
5. “Vacuum” Light - Illuminates when adjusting the vacuum time.
It also illuminates during the vacuum process.
6. LED Display - Displays current cycle time in seconds.
7. Set Button - Press to set the vacuum or sealing time,
then use the up/down arrow buttons to make adjustments.
8. Down & Up Arrow Buttons - Press to decrease/increase the
vacuum, sealing, or cooling time.
9. Stop Button - Press to stop the vacuum cycle and seal the
bag immediately.
GAS
SEALING
COOLING
VACUUM
Set
StopDown Up
1
7 8 9
6
2 3 4 5
4.
